Specifications
| Model | M76004GT4VS |
| Module service port | 4 x 10/100/1000BASE-T ports
4 x 1GE/10GE/25GE SFP28 ports |
| Transmission
Medium |
10/100/1000BASE-T Cat 5 UTP
1000BASE-X to 1000BASE T CAT5e/6/6a 1000BASE-SX (850 nm) 1000BASE-LX (1310 nm) 1000BASE-LH (1310 nm) 1000BASE-ZX (1550 nm) 1000BASE-LX (1310 nm, 1550 nm) 10GBASE-SR (850 nm) 10GBASE-LR (1310 nm) 10GBASE-ER (1550 nm) 10GBASE-ZR (1550 nm) 10GBASE SFP+ active optical cable (AOC) 25GBASE-SR (850 nm) 25GBASE-LR (1310 nm) |
| Status LED | 1 x system status LED
4 x 10/100/1000BASE-T port LEDs 2 x 1GE/10GE/ 25GE SFP28 port LEDs |
| Module power
consumption |
13.06 W |
| Module dimensions
(W x D x |
130 mm x 90.5 mm x 40 mm (5.12 in. x 3.56 in. x 1.57 in.) |
| Module weight | 0.3 kg (0.66 lbs) |
| Temperature | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: 40°C to +70°C 40°F to +158°F) Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
| Humidity | Operating humidity: 10% to 90% RH (noncondensing)
Storage humidity: 5% to 95% RH (noncondensing) |
| Acoustic noise | <78dB |
| Module hot swapping | Supported |
| Cable hot swapping | Supported |
| Safety regulation | IEC 62368-1: 2018
EN 62368-1: 2014+A11:2017 |
| EMC regulation | EN 55032:2015+A1:2020
EN 61000-3 2013+A1:2019+A2:2021 EN IEC 61000-3 2:2019+A1:2021 EN 55035:2017+A11:2020 EN 300386 V2.2.1 |
| RoHS | European RoHS Directive 2011/65/EU & Amendment(EU) 2015/863 |
