Specifications
| Model | M7600 2CQ |
| Module service port | 2 x 40GE/100GE QSFP28 ports |
| Transmission
Medium |
40GBASE LSR (850 nm)
40GBASE LR4 (1310 nm) 40GBASE iLR4 (1310 nm) 40GBASE LX4 (1310 nm) 40GBASE QSFP+ active optical cable (AOC) 100GBASE SR (850 nm) 100GBASE LR4 (1310 nm) 100GBASE QSFP28 active optical cable (AOC) |
| Status LED | 1 x system status LED
2 x 40GE/100GE QSFP28 port LEDs |
| Module power
consumption |
13.06 W |
| Module dimensions
(W x D x |
130 mm x 90.5 mm x 40 mm (5.12 in. x 3.56 in. x 1.57 in.) |
| Module weight | 0.2 kg (0.44 lbs) |
| Temperature | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: 40°C to +70°C ( 40°F to +158°F)
Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
| Humidity | Operating humidity: 10% to 90% RH (noncondensing)
Storage humidity: 5% to 95% RH (noncondensing) |
| Acoustic noise | <78dB |
| Module hot swapping | Supported |
| Cable hot swapping | Supported |
| Safety regulation | IEC 62368-1: 2018
EN 62368-1: 2014+A11:2017 |
| EMC regulation | EN 55032:2015+A1:2020
EN 61000-3 2013+A1:2019+A2:2021 EN IEC 61000-3 2:2019+A1:2021 EN 55035:2017+A11:2020 EN 300386 V2.2.1 |
| RoHS | European RoHS Directive 2011/65/EU & Amendment(EU) 2015/863 |
